22mm 2N1 Rocker Nav/Anchor Light Switch, +12V

Bluewater 22mm 2N1 Rocker Nav/Anchor Light Switch, +12V

Model: 9059-7014

• Nav/Anchor Rocker — Press the top to turn on nav and anchor lights, press the bottom for anchor light only.
• Latching Operation — Press either side again to turn the lights off.
• LED Feedback — Blue backlight, green with nav + anchor on and red with anchor only.
• Dual Outputs — 10A per channel, 20A combined, switching +12V.
• IP69K Waterproof — Sealed SS316 stainless steel body withstands salt spray, washdowns and submersion.

The Bluewater 9059-7014 is a 22mm 2N1 switch with a rocker-style actuator that puts navigation and anchor lighting on a single cutout.

Built with an SS316 stainless steel case and IP69K sealing for harsh marine environments.

Installation: Drill a 22mm mounting hole and plug in a Bluewater 22mm Deutsch-style harness.

Specifications

Function	Latching: Top = Nav + Anchor, Bottom = Anchor only
Output	+12V switched
LED Indicators	Blue backlight / Green nav + anchor / Red anchor only
Voltage/Current	10A per channel, 20A combined @ 12VDC
Protection Rating	IP69K
Material	Nickel-plated brass / SS316 stainless steel
Mechanical Life	50,000 cycles
Electrical Life	10,000 cycles
Mounting Hole	22mm
Connector	Deutsch-style (22mm harness 9053-3914 sold separately)
